Tube Fittings
Cone and Thread Fittings, 150,000 PSI - F Series

Parker Autoclave's F Series are high pressure cone and thread fittings for use in a variety of applications with 1/4" to 1" Parker Autoclave tubing. These cone and thread fittings are rated to 150,000 psi (10342 bar).

Parker Autoclave's F Series and SF Series high pressure fittings utilize a special designed collar to secure the tube connection. These cone and thread fittings are used as fluid handling components in specialty systems up to 150,000 PSI (10342 BAR) with Parker Autoclave Tubing. These high quality, high pressure components provide dependable performance in gas and liquid applications.

Cone and Thread Fittings, 150,000 PSI - F Series

Markets:
- Chemical
- Petrochemical
- Oil and Gas
- Food Preparation
- Water Blast Industries


Features/Benefits:
- Coned-and-threaded connection
- Tubing sizes are 1/4", 5/16", 3/8", 9/16", and 1"
- Fittings manufactured from cold worked 316 stainless steel
- Anti-vibration connections components available
- Autofrettaged tubing
- Operating temperatures from -423oF (-252oC ) to 1200oF (649oC)
- Available in special materials

Applications:
- Water Jet Cutting Systems
- LDPE systems
- HPP Food Processing Lines
- Water Blasting

Technical Specifications

Cone and Thread Fittings, 150,000 PSI - F Series 型号
