Hose Fittings
High Pressure Gland Nuts
High pressure gland nuts are designed to be used with Polyflex fittings.
High pressure gland nuts are designed to be used with Polyflex fittings.
Markets:
? Hydraulics
? Industrial
? Oil & Gas
Markets:
? Hydraulics
? Industrial
? Oil & Gas
Markets:
- Hydraulics
- Industrial
- Oil & Gas
Technical Specifications
| Connection Thread Size: |
7/16 (20 UNF), 9/16 (18 UNF), 13/16 (16 UNF), 3/4 (14 NPS), 1-3/8 (12 UNF), 3/4 (16 UNF), 1-1/8 (12 UNF) inch |
| Shape: |
Straight |
| Application: |
Oilfield, Marine |
| Connection Type: |
Field-Attachable |
| Hose Inside Diameter: |
1/4, 3/8, 9/16, 3/4, 1 inch, 6, 10, 14, 19, 25 mm |
| Maximum Operating Pressure: |
4140 bar, 414 MPa, 60,000 psi, 20000, 60000 psi, 138, 414 MPa |
| Hex Size: |
0.5, 0.625, 0.813, 0.75, 1.375, 1.188, 0.63, 0.68, 1.68 inch, 12.7, 15.88, 20.64, 19.05, 34.93, 15.89, 30.16, 16, 17.27, 42.67 mm |
| Materials of Construction: |
Stainless Steel |
High Pressure Gland Nuts 型号
|
