Parker 3-Way Normally Closed, 1/8" General Purpose Solenoid Valves
Parkers' 3-Way Normally Closed G 1/8" Solenoid Valves provide operating pressures up to 15 bar and flow factors up to 0.21 m3/h. They offer multiple body and sealing materials for all general purpose fluid control applications.
Parker's 3-Way Controlled by Normally Closed G 1/8" Solenoid Valves are used in a wide variety of applications with or without pressure differential. Ideally suited for air, liquids and gases, these valves are mainly available with brass or stainless steel body associated to a large range of sealing materials offering vast chemical compatibilities.
Parker 3-Way Normally Closed, 1/8" General Purpose Solenoid Valves
Markets:
- Beverage
- Life Science
- Industrial Equipment
Features/Benefits:
- Robust and solid design
- Ideally suited for air, liquids and gases
- Brass or stainless steel body
Applications:
- Compressors
- Water dispensing & purification
- Cooling systems
- Sterilizers
- Analyzers and diagnostic equipment
- Medical and dental devices
- Welding equipment
- Lubrication equipment
- Beverage dispensing & vending machines
- Oil burners
- Humidification and misting equipment
- Mobile equipment
- Textile and dry cleaning machines
- Irrigation
Technical Specifications
| Product Series: |
General Purpose Solenoid Valves |
| Valve Type: |
3-Way |
| Function: |
Normally Closed |
| Port Size: |
1/8 inch |
| Input Voltage: |
115-240VAC/50-60Hz or 24VDC |
| Body Material: |
Brass, Anodized Aluminium or 316L Stainless St. |
| Seal Material: |
FKM, NBR, TPE/PTVF |
| Orifice 1 Size: |
1.2 to 2.5 mm |
| Flow Coefficient 1: |
0.04 to 0.21 m3/hour, 0.7 to 3.5 L/min |
| Power Consumption: |
2 to 14 W |
| Coil Type: |
DIN, Screw, Explosion Proof and Flame Proof, from 22 to 40 mm |
| Maximum Pressure Differential: |
5 to 15 bar |
| Minimum Pressure Differential: |
0 bar |
| Number of Ports: |
3 |
| Actuation Type: |
Direct Operated |
| Media: |
General Purpose for Air, Liquids, Gases and Oil |
| Port Type: |
BSP |
| Orifice 2 Size: |
1.5 to 2.5 mm |
| Flow Coefficient 2: |
0.05 to 0.7 m3/hour, 0.9 to 3.5 L/min |
| Minimum Fluid Temperature: |
-10 °C |
| Maximum Fluid Temperature: |
140 °C |
| Coil Specifications Met: |
IP44, IP65, IP67 or IP69K |
Parker 3-Way Normally Closed, 1/8" General Purpose Solenoid Valves型号
| Part |
Voltage (V) |
Body Material |
Seal Material |
Orifice 1 Size (mm) |
Flow Factor 1 (l/min) |
Power (Watts) |
Coil Type |
| 131B14-482605C2 |
24VDC |
Anodized Aluminium |
NBR |
1.2 |
0.8 |
5 |
Explosion proof encapsulated electrical part "mb", 32 mm |
| 131B14-496131C2 |
24VDC |
Anodized Aluminium |
NBR |
1.2 |
0.8 |
3 |
Coil for DIN plug connection, double frequency, 22 mm |
| 131B14-496131P9 |
230VAC/50-60Hz |
Anodized Aluminium |
NBR |
1.2 |
0.8 |
3 |
Coil for DIN plug connection, double frequency, 22 mm |
| 131B14-496482C2 |
24VDC |
Anodized Aluminium |
NBR |
1.2 |
0.8 |
3 |
Coil for DIN plug connection, double frequency coil, 22 mm |
| 131B14-496482P9 |
230VAC/50-60Hz |
Anodized Aluminium |
NBR |
1.2 |
0.8 |
3 |
Coil for DIN plug connection, double frequency coil, 22 mm |
| 131B14-496637C2 |
24VDC |
Anodized Aluminium |
NBR |
1.2 |
0.8 |
3 |
Explosion proof electrical part "nAc nCc", double frequency, 22 mm |
| 131B14-496637P9 |
230VAC/50-60Hz |
Anodized Aluminium |
NBR |
1.2 |
0.8 |
3 |
Explosion proof electrical part "nAc nCc", double frequency, 22 mm |
| 131K0648-2161-495294C2 |
24VDC |
Brass |
TPE/PVDF |
1.8 |
1.7 |
9 |
Coil with ISO-DIN connector, 12-24VDC for transportation applications, 32 mm |
| 131K0648-2161-496193C2 |
24VDC |
Brass |
TPE/PVDF |
1.8 |
1.7 |
9 |
Coil with ISO-DIN connector, 12-24VDC, for transportation applications, 32 mm |
| 131K16-2995-4818653D |
220-230VAC/50Hz |
Brass |
FKM |
2 |
2.5 |
8 |
Coil for DIN plug connection, 32 mm |
| 131K16-2995-481865C2 |
24VDC |
Brass |
FKM |
2 |
2.5 |
9 |
Coil for DIN plug connection, 32 mm |
| 131K16-2995-4958703D |
220-230VAC/50Hz |
Brass |
FKM |
2 |
2.5 |
8 |
Explosion proof electrical part "nAc nCc", 32 mm |
| 131K16-2995-495870C2 |
24VDC |
Brass |
FKM |
2 |
2.5 |
9 |
Explosion proof electrical part "nAc nCc", 32 mm |
| 131K16-4270-4810003D |
220-230VAC/50Hz |
Brass |
FKM |
2 |
2.5 |
8 |
Coil with screw terminal, 40 mm |
| 131K16-4270-481000C2 |
24VDC |
Brass |
FKM |
2 |
2.5 |
8 |
Coil with screw terminal, 40 mm |
| 131M14-482606C2 |
24VDC |
Brass |
FKM |
1.5 |
0.9 |
2.5 |
Explosion proof encapsulated electrical part "mb", low power, 32 mm |
| 131M14-826063D |
220-230VAC/50Hz |
Brass |
FKM |
1.5 |
0.9 |
2 |
Explosion proof encapsulated electrical part "mb", low power, 32 mm |
| 131M14-8993-4889803D |
220-230VAC/50Hz |
Brass |
FKM |
1.5 |
0.9 |
2 |
Coil for DIN plug connection, low power, 22 mm |
| 131M14-8993-488980C2 |
24VDC |
Brass |
FKM |
1.5 |
0.9 |
2.5 |
Coil for DIN plug connection, low power, 22 mm |
| 131M14-8993-4958653D |
220-230VAC/50Hz |
Brass |
FKM |
1.5 |
0.9 |
2 |
Explosion proof electrical part "nAc nCc", low power, 22 mm |
| 131M14-8993-495865C2 |
24VDC |
Brass |
FKM |
1.5 |
0.9 |
2.5 |
Explosion proof electrical part "nAc nCc", low power, 22 mm |
| 131M15-4826063D |
220-230VAC/50Hz |
Brass |
FKM |
1.2 |
0.7 |
2 |
Explosion proof encapsulated electrical part "mb", low power, 32 mm |
| 131M15-482606C2 |
24VDC |
Brass |
FKM |
1.2 |
0.7 |
2.5 |
Explosion proof encapsulated electrical part "mb", low power, 32 mm |
| 131M15-8993-4889803D |
220-230VAC/50Hz |
Brass |
FKM |
1.2 |
0.7 |
2 |
Coil for DIN plug connection, low power, 22 mm |
| 131M15-8993-488980C2 |
24VDC |
Brass |
FKM |
1.2 |
0.7 |
2.5 |
Coil for DIN plug connection, low power, 22 mm |
| 131M15-8993-4958653D |
220-230VAC/50Hz |
Brass |
FKM |
1.2 |
0.7 |
2 |
Explosion proof electrical part "nAc nCc", low power, 22 mm |
| 131M15-8993-495865C2 |
24VDC |
Brass |
FKM |
1.2 |
0.7 |
2.5 |
Explosion proof electrical part "nAc nCc", low power, 22 mm |
| 398130U |
115VAC/60Hz |
Brass |
FKM |
1.5 |
1 |
4.5 |
Coil for DIN plug connection, 22 mm |
| 398132 |
230VAC/50-60Hz |
Brass |
FKM |
2 |
1.5 |
4.5 |
Coil for DIN plug connection, 22 mm |
| 398134U |
115VAC/60Hz |
Brass |
FKM |
2 |
1.5 |
4.5 |
Coil for DIN plug connection, 22 mm |
| 398136U |
208-240VAC/60Hz |
Brass |
FKM |
2 |
1.5 |
4.5 |
Coil for DIN plug connection, 22 mm |
| 398138 |
115VAC/50-60Hz |
Brass |
FKM |
1.5 |
1 |
4.5 |
Coil for DIN plug connection, 22 mm |
| 398142 |
240VAC/50-60Hz |
Brass |
FKM |
1.5 |
1 |
4.5 |
Coil for DIN plug connection, 22 mm |
| 550014DIS |
24VDC |
316L Stainless St. |
FKM |
1.5 |
1 |
5 |
- |
| 550015DIS |
220-230VAC/50Hz |
316L Stainless St. |
FKM |
1.5 |
1 |
4 |
- |
| 550062DIS |
230VAC/50-60Hz |
Brass |
FKM |
1.5 |
1 |
4.5 |
Coil for DIN plug connection, 22 mm |
| 550063DIS |
230VAC/50-60Hz |
Brass |
FKM |
1.2 |
0.7 |
4.5 |
Coil for DIN plug connection, 22 mm |
| 550219DIS |
24VDC |
Brass |
FKM |
1.5 |
1 |
5 |
Coil for DIN plug connection, 22 mm |
| 550220DIS |
24VDC |
Brass |
FKM |
1.2 |
0.7 |
5 |
Coil for DIN plug connection, 22 mm |
| E131K13-2995-4818653D |
220-230VAC/50Hz |
Brass |
FKM |
2.5 |
3.5 |
8 |
Coil for DIN plug connection, 32 mm |
| E131K13-2995-481865C2 |
24VDC |
Brass |
FKM |
2.5 |
3.5 |
9 |
Coil for DIN plug connection, 32 mm |
| E131K13-2995-4958703D |
220-230VAC/50Hz |
Brass |
FKM |
2.5 |
3.5 |
8 |
Explosion proof electrical part "nAc nCc", 32 mm |
| E131K13-2995-495870C2 |
24VDC |
Brass |
FKM |
2.5 |
3.5 |
9 |
Explosion proof electrical part "nAc nCc", 32 mm |
| E131K13-4270-4810003D |
220-230VAC/50Hz |
Brass |
FKM |
2.5 |
3.5 |
8 |
Coil with screw terminal, 40 mm |
| E131K13-4270-481000C2 |
24VDC |
Brass |
FKM |
2.5 |
3.5 |
8 |
Coil with screw terminal, 40 mm |
| E131K13-4270-486265C2 |
24VDC |
Brass |
FKM |
2.5 |
3.5 |
14 |
Coil with screw terminal,high temperature-high power, 40 mm |
| E131K13-4270-486265F4 |
230VAC/50Hz |
Brass |
FKM |
2.5 |
3.5 |
14 |
Coil with screw terminal,high temperature-high power, 40 mm |
| E131K13-495905C2 |
24VDC |
Brass |
FKM |
2.5 |
3.5 |
8 |
Flame proof encapsulated electrical part "db mb", 37 mm |
| E131K13-495905F4 |
230VAC/50Hz |
Brass |
FKM |
2.5 |
3.5 |
8 |
Flame proof encapsulated electrical part "db mb", 37 mm |
| E131K14-2995-4818653D |
220-230VAC/50Hz |
Brass |
FKM |
1.5 |
1.5 |
8 |
Coil for DIN plug connection, 32 mm |
| E131K14-2995-481865C2 |
24VDC |
Brass |
FKM |
1.5 |
1.5 |
9 |
Coil for DIN plug connection, 32 mm |
| E131K14-4270-4810003D |
220-230VAC/50Hz |
Brass |
FKM |
1.5 |
1.5 |
8 |
Coil with screw terminal, 40 mm |
| E131K14-4270-481000C2 |
24VDC |
Brass |
FKM |
1.5 |
1.5 |
8 |
Coil with screw terminal, 40 mm |
| E133K14-2995-4958703D |
220-230VAC/50Hz |
Brass |
FKM |
1.5 |
1.5 |
8 |
Explosion proof electrical part "nAc nCc", 32 mm |
| E133K14-2995-495870C2 |
24VDC |
Brass |
FKM |
1.5 |
1.5 |
9 |
Explosion proof electrical part "nAc nCc", 32 mm |
|
