Parker派克电磁阀
Parker Solenoid Valves
Parker 5-Way Spring Return, 1/8" General Purpose Solenoid Valves

Parkers' 5-Way Spring Return G 1/8" Solenoid Valves provide operating pressures up to 10 bar and flow factors up to 0.54 m3/h. They offer multiple body and sealing materials for all general purpose fluid control applications.





Parkers' 5-Way Spring Return G 1/8" Solenoid Valves are used in a wide variety of applications with or without pressure differential. Ideally suited for air, liquids and gases, these valves are mainly available with brass or stainless steel body associated to a large range of sealing materials offering vast chemical compatibilities .
Markets:
- Life Science
- Process
- Industrial Equipment
- Beverage
Features/Benefits:
- General Purpose for Air, Liquids, Gases and Oil
- Brass or Stainless steel body
Applications:
- Compressors
- Water dispensing & purification
- Cooling systems
- Sterilizers
- Analyzers and diagnostic equipment
- Medical and dental devices
- Welding equipment
- Lubrication equipment
- Beverage dispensing & vending machines
- Oil burners
- Humidification and misting equipment
- Mobile equipment
- Textile and dry cleaning machines
- Irrigation





Technical Specifications

Product Series: General Purpose Solenoid Valves
Valve Type: 5-Way
Function: Spring Return
Port Size: 1/8 inch
Input Voltage: 220-230VAC/50Hz or 24/28VDC
Body Material: Anodized Aluminium and POM
Seal Material: NBR, FKM, NBR/PUR
Orifice 1 Size: 4 to 15 mm
Flow Coefficient 1: 0.3 to 0.54 m3/hour, 5 to 12 L/min
Power Consumption: 0.3 to 14 W
Coil Type: DIN, Screw, Explosion Proof and Flame Proof, from 22 to 50 mm
Maximum Pressure Differential: 10 bar
Minimum Pressure Differential: 1 to 2 bar
Number of Ports: 5
Actuation Type: Pilot Operated
Media: General Purpose for Air, Liquids, Gases and Oil
Port Type: BSP, CETOP
Orifice 2 Size: n/a
Flow Coefficient 2: n/a, n/a
Minimum Fluid Temperature: n/a
Maximum Fluid Temperature: n/a
Coil Specifications Met: IP44, IP65, IP67



Parker 5-Way Spring Return, 1/8" General Purpose Solenoid Valves型号

Part Voltage (V) Body Material Seal Material Orifice 1 Size (mm) Flow Factor 1 (l/min) Power (Watts) Coil Type
341B34-2995-4818653D 220-230VAC/50Hz Anodized Aluminium FKM 6 9 8 Coil for DIN plug connection, 32 mm
341B34-2995-481865C2 24VDC Anodized Aluminium FKM 6 9 9 Coil for DIN plug connection, 32 mm
341B34-4270-4810003D 220-230VAC/50Hz Anodized Aluminium FKM 6 9 8 Coil with screw terminal, 40 mm
341B34-4270-481000C2 24VDC Anodized Aluminium FKM 6 9 8 Coil with screw terminal, 40 mm
341B34-4270-486265C2 24VDC Anodized Aluminium FKM 6 9 14 Coil with screw terminal,high temperature-high power, 40 mm
341B34-4270-486265F4 230VAC/50Hz Anodized Aluminium FKM 6 9 14 Coil with screw terminal,high temperature-high power, 40 mm
341B3403-2995-4958703D 220-230VAC/50Hz Anodized Aluminium FKM 6 9 8 Explosion proof electrical part "nAc nCc", 32 mm
341B3403-2995-495870C2 24VDC Anodized Aluminium FKM 6 9 9 Explosion proof electrical part "nAc nCc", 32 mm
341B3403-495905C2 24VDC Anodized Aluminium FKM 6 9 8 Flame proof encapsulated electrical part "db mb", 37 mm
341B3403-495905F4 230VAC/50Hz Anodized Aluminium FKM 6 9 8 Flame proof encapsulated electrical part "db mb", 37 mm
341B3490-2995-483580.01N7 28VDC Anodized Aluminium NBR 6 9 0.5 to 3 Explosion proof intrinsically safe electrical part "ia", 32 mm
341B3490-488660.01N7 28VDC Anodized Aluminium NBR 6 9 0.3 to 3 Explosion proof intrinsically safe electrical part "ia", 50 mm
341B3490-495910N7 28VDC Anodized Aluminium NBR 6 9 0.3 to 3 Explosion proof intrinsically safe electrical part "ia", "booster", 37 mm
341L0197-2995-482740C2 24VDC POM NBR 6 12 1.6 Coil for DIN plug connection, low power, 32 mm
341L0197-2995-496125C2 24VDC POM NBR 6 12 1.6 Explosion proof electrical part "nAc nCc", low power, 32 mm
341L0197-495900C2 24VDC POM NBR 6 12 2 Flame proof encapsulated electrical part "db mb", low power, 37 mm
341L0197-495900F4 230VAC/50Hz POM NBR 6 12 2.5 Flame proof encapsulated electrical part "db mb", low power, 37 mm
341L0197-495910N7 28VDC POM NBR 6 12 0.3 to 3 Explosion proof intrinsically safe electrical part "ia", "booster", 37 mm
341L04-482605C2 24VDC POM FKM 8 12 5 Explosion proof encapsulated electrical part "mb", 32 mm
341L04-4826063D 220-230VAC/50Hz POM FKM 8 12 2 Explosion proof encapsulated electrical part "mb", low power, 32 mm
341L04-482606C2 24VDC POM FKM 8 12 2.5 Explosion proof encapsulated electrical part "mb", low power, 32 mm
341L04-8993-4889803D 220-230VAC/50Hz POM FKM 8 12 2 Coil for DIN plug connection, low power, 22 mm
341L04-8993-488980C2 24VDC POM FKM 8 12 2.5 Coil for DIN plug connection, low power, 22 mm
341L04-8993-4958653D 220-230VAC/50Hz POM FKM 8 12 2 Explosion proof electrical part "nAc nCc", low power, 22 mm
341L04-8993-495865C2 24VDC POM FKM 8 12 2.5 Explosion proof electrical part "nAc nCc", low power, 22 mm
341L05-482605C2 24VDC POM NBR 6 12 5 Explosion proof encapsulated electrical part "mb", 32 mm
341L05-4826063D 220-230VAC/50Hz POM NBR 6 12 2 Explosion proof encapsulated electrical part "mb", low power, 32 mm
341L05-482606C2 24VDC POM NBR 6 12 2.5 Explosion proof encapsulated electrical part "mb", low power, 32 mm
341L05-8993-4889803D 220-230VAC/50Hz POM NBR 6 12 2 Coil for DIN plug connection, low power, 22 mm
341L05-8993-488980C2 24VDC POM NBR 6 12 2.5 Coil for DIN plug connection, low power, 22 mm
341L05-8993-4958653D 220-230VAC/50Hz POM NBR 6 12 2 Explosion proof electrical part "nAc nCc", low power, 22 mm
341L05-8993-495865C2 24VDC POM NBR 6 12 2.5 Explosion proof electrical part "nAc nCc", low power, 22 mm
341L9101-482605C2 24VDC Anodized Aluminium NBR 4 5 5 Explosion proof encapsulated electrical part "mb", 32 mm
341L9101-8993-4958653D 220-230VAC/50Hz Anodized Aluminium NBR 4 5 2 Explosion proof electrical part "nAc nCc", low power, 22 mm
341L9101-8993-495865C2 24VDC Anodized Aluminium NBR 4 5 2.5 Explosion proof electrical part "nAc nCc", low power, 22 mm
341P01-4826063D 220-230VAC/50Hz Anodized Aluminium NBR 4 9 2 Explosion proof encapsulated electrical part "mb", low power, 32 mm
341P01-482606C2 24VDC Anodized Aluminium NBR 4 9 2.5 Explosion proof encapsulated electrical part "mb", low power, 32 mm
341P01-8993-4889803D 220-230VAC/50Hz Anodized Aluminium NBR 4 9 2 Coil for DIN plug connection, low power, 22 mm
341P01-8993-488980C2 24VDC Anodized Aluminium NBR 4 9 2.5 Coil for DIN plug connection, low power, 22 mm
341P21-2995-4818653D 220-230VAC/50Hz Anodized Aluminium NBR 4 9 8 Coil for DIN plug connection, 32 mm
341P21-2995-481865C2 24VDC Anodized Aluminium NBR 4 9 9 Coil for DIN plug connection, 32 mm
341P21-4270-4810003D 220-230VAC/50Hz Anodized Aluminium NBR 4 9 8 Coil with screw terminal, 40 mm
341P21-4270-481000C2 24VDC Anodized Aluminium NBR 4 9 8 Coil with screw terminal, 40 mm
341P2108-2995-4818653D 220-230VAC/50Hz Anodized Aluminium NBR/PUR 4 9 8 Coil for DIN plug connection, 32 mm
341P2108-2995-481865C2 24VDC Anodized Aluminium NBR/PUR 4 9 9 Coil for DIN plug connection, 32 mm
341P2108-2995-4958703D 220-230VAC/50Hz Anodized Aluminium NBR/PUR 4 9 8 Explosion proof electrical part "nAc nCc", 32 mm
341P2108-2995-495870C2 24VDC Anodized Aluminium NBR/PUR 4 9 9 Explosion proof electrical part "nAc nCc", 32 mm
341P2108-4270-4810003D 220-230VAC/50Hz Anodized Aluminium NBR/PUR 4 9 8 Coil with screw terminal, 40 mm
341P2108-4270-481000C2 24VDC Anodized Aluminium NBR/PUR 4 9 8 Coil with screw terminal, 40 mm
341P2190-2995-483580.01N7 28VDC Anodized Aluminium NBR 15 9 0.5 to 3 Explosion proof intrinsically safe electrical part "ia", 32 mm
341P2190-488660.01N7 28VDC Anodized Aluminium NBR 15 9 0.3 to 3 Explosion proof intrinsically safe electrical part "ia", 50 mm
341P2190-495910N7 28VDC Anodized Aluminium NBR 15 9 0.3 to 3 Explosion proof intrinsically safe electrical part "ia", "booster", 37 mm
341P2197-2995-482740C2 24VDC Anodized Aluminium NBR/PUR 4 9 1.6 Coil for DIN plug connection, low power, 32 mm
341P2197-2995-496125C2 24VDC Anodized Aluminium NBR/PUR 4 9 1.6 Explosion proof electrical part "nAc nCc", low power, 32 mm
341P2197-495900C2 24VDC Anodized Aluminium NBR/PUR 4 9 2 Flame proof encapsulated electrical part "db mb", low power, 37 mm
341P2197-495900F4 230VAC/50Hz Anodized Aluminium NBR/PUR 4 9 2.5 Flame proof encapsulated electrical part "db mb", low power, 37 mm
341P2197-495910N7 28VDC Anodized Aluminium NBR/PUR 4 9 0.3 to 3 Explosion proof intrinsically safe electrical part "ia", "booster", 37 mm
E341L01-2995.33-491514C2 24VDC POM FKM 6 12 12 Coil for DIN plug connection, 32 mm, UL class F
E341L01-4833713D 220-230VAC/50Hz POM FKM 6 12 8 Explosion proof increased safety electrical part "eb", 50 mm
E341L01-483371C2 24VDC POM FKM 6 12 8 Explosion proof increased safety electrical part "eb", 50 mm
E341L02-2995-4818653D 220-230VAC/50Hz POM FKM 6 12 8 Coil for DIN plug connection, 32 mm
E341L02-2995-481865C2 24VDC POM FKM 6 12 9 Coil for DIN plug connection, 32 mm
E341L02-4270-4810003D 220-230VAC/50Hz POM FKM 6 12 8 Coil with screw terminal, 40 mm
E341L02-4270-481000C2 24VDC POM FKM 6 12 8 Coil with screw terminal, 40 mm
