Parker Adapters
Type "M" Fitting Adapters
These fitting adapters connect to Type "M" Swivel end fittings and seal with a 58° cone.
Parker's Type "M" fitting adapters provide a quick and easy connection for hose assemblies. These are our highest rated adapters - rated to the full working pressure of the hose or hose end connection. Type "M" fitting adapters are versitile and ideal for any application where ease of connection and working pressure are important.
Type "M" Fitting Adapters
Markets:
- Waterblast / Water Jetting
- Hydraulics
- Oil & Gas
Features/Benefits:
- Provides a swivel for quick and easy connection
- Internal threads and seal are protected from external damage
- Non-rotating seal reduces galling and minimizes tightening torque
- Can be adapted to almost any connection required
Applications:
- Any system requiring Type "M" connections for hose assemblies
Technical Specifications
| Connection 1 Size: |
Male Straight, Torpedo, Torpedo with Gland Nut and Collar |
| Connection 2 Size: |
Type "M" Male, High Pressure Male, Med. Pressure Male, BSP Male, Torpedo, Torpedo with Gland Nut and Collar |
| Connection 1 Thread Size: |
9/16 - 18 UNF, 3/4 - 16 UNF, 7/8 - 14 UNF, 1 - 12 UNF, 1-5/16 - 12 UNF inch |
| Connection 2 Thread Size: |
9/16 - 18 UNF, 3/4 - 16 UNF, 7/8 - 14 UNF, 7/8 14 UNF, 1 - 12 UNF, 1-5/16 - 12 UNF, 1-1/8 - 12 UNF, 7/16 - 20 UNF, 13/16 - 16 UNF, 3/4 - 14 NPS, 1/4 - 18 BSP, 3/8 - 18 BSP, 1/2 - 14 BSP inch |
| Materials of Construction: |
316 Stainless Steel |
| Overall Length: |
varies inch, varies mm |
| Hex Size: |
0.63, 0.75, 1.00, 1.38, 1.13, 0.88, 0.88 inch, 16.00, 19.05, 25.40, 35.05, 28.70, 22.35, 22.23 mm |
| Maximum Operating Pressure: |
30000, 20000, or 60000 psi, 138, 207 or 414 MPa |
Type "M" Fitting Adapters型号
| Part |
Connection 1 Style |
Connection 2 Style |
Connection 1 Thread Size (inch) |
Connection 2 Thread Size (inch) |
| YAD9-6-4C |
Type "M" Male |
BSP Male |
9/16 - 18 UNF |
1/4 - 18 BSP |
| YAD9-6-6C |
Type "M" Male |
BSP Male |
9/16 - 18 UNF |
3/8 - 18 BSP |
| YAD9-6-8C |
Type "M" Male |
BSP Male |
9/16 - 18 UNF |
1/2 - 14 BSP |
| YAY1-11-16C |
Torpedo |
Torpedo |
1 - 12 UNF |
1 - 14 UNS LH |
| YAY1-16-16C |
Torpedo |
Torpedo |
1-5/16 - 12 UNF |
1 - 14 UNS LH |
| YAY1-8-16C |
Torpedo |
Torpedo |
3/4 - 16 UNF |
1 - 14 UNS LH |
| YAY2-11-16C |
Torpedo with Gland Nut and Collar |
Torpedo with Gland Nut and Collar |
1 - 12 UNF |
1 - 14 UNS LH |
| YAY2-16-16C |
Torpedo with Gland Nut and Collar |
Torpedo with Gland Nut and Collar |
1-5/16 - 12 UNF |
1 - 14 UNS LH |
| YAY2-8-16C |
Torpedo with Gland Nut and Collar |
Torpedo with Gland Nut and Collar |
3/4 - 16 UNF |
1 - 14 UNS LH |
| YAY5-11-12C |
Type "M" Male |
Medium Pressure Male |
1 - 12 UNF |
3/4 - 14 NPS |
| YAY5-11-4C |
Type "M" Male |
Medium Pressure Male |
1 - 12 UNF |
7/16 - 20 UNF |
| YAY5-11-6C |
Type "M" Male |
Medium Pressure Male |
1 - 12 UNF |
9/16 - 18 UNF |
| YAY5-11-9C |
Type "M" Male |
Medium Pressure Male |
1 - 12 UNF |
13/16 - 16 UNF |
| YAY5-16-12C |
Type "M" Male |
Medium Pressure Male |
1-5/16 - 12 UNF |
13/16 - 16 UNF |
| YAY5-16-9C |
Type "M" Male |
Medium Pressure Male |
1-5/16 - 12 UNF |
9/16 - 18 UNF |
| YAY5-6-12C |
Type "M" Male |
Medium Pressure Male |
9/16 - 18 UNF |
3/4 - 14 NPS |
| YAY5-6-4C |
Type "M" Male |
Medium Pressure Male |
9/16 - 18 UNF |
7/16 - 20 UNF |
| YAY5-6-6C |
Type "M" Male |
Medium Pressure Male |
9/16 - 18 UNF |
9/16 - 18 UNF |
| YAY5-6-9C |
Type "M" Male |
Medium Pressure Male |
9/16 - 18 UNF |
13/16 - 16 UNF |
| YAY5-8-12C |
Type "M" Male |
Medium Pressure Male |
3/4 - 16 UNF |
3/4 - 14 NPS |
| YAY5-8-4C |
Type "M" Male |
Medium Pressure Male |
3/4 - 16 UNF |
7/16 - 20 UNF |
| YAY5-8-6C |
Type "M" Male |
Medium Pressure Male |
3/4 - 16 UNF |
9/16 - 18 UNF |
| YAY5-8-9C |
Type "M" Male |
Medium Pressure Male |
3/4 - 16 UNF |
13/16 - 16 UNF |
| YAY6-10-6C |
Type "M" Male |
High Pressure Male |
7/8 - 14 UNF |
3/4 - 16 UNF |
| YAY6-10-9C |
Type "M" Male |
High Pressure Male |
7/8 - 14 UNF |
1-1/8 - 12 UNF |
| YAY6-11-9C |
Type "M" Male |
High Pressure Male |
1 - 12 UNF |
1-1/8 - 12 UNF |
| YAY6-6-4C |
Type "M" Male |
High Pressure Male |
9/16 - 18 UNF |
9/16 - 18 UNF |
| YAY6-6-6C |
Type "M" Male |
High Pressure Male |
9/16 - 18 UNF |
3/4 - 16 UNF |
| YAY6-6-9C |
Type "M" Male |
High Pressure Male |
9/16 - 18 UNF |
1-1/8 - 12 UNF |
| YAY6-8-6C |
Type "M" Male |
High Pressure Male |
3/4 - 16 UNF |
3/4 - 16 UNF |
| YAY6-8-9C |
Type "M" Male |
High Pressure Male |
3/4 - 16 UNF |
1-1/8 - 12 UNF |
| YAYA-10-10C |
Type "M" Male |
Type "M" Male |
7/8 - 14 UNF |
7/8 - 14 UNF |
| YAYA-10-6C |
Type "M" Male |
Type "M" Male |
7/8 - 14 UNF |
9/16 - 18 UNF |
| YAYA-11-10C |
Type "M" Male |
Type "M" Male |
1 - 12 UNF |
7/8 14 UNF |
| YAYA-11-11C |
Type "M" Male |
Type "M" Male |
1 - 12 UNF |
1 - 12 UNF |
| YAYA-11-8C |
Type "M" Male |
Type "M" Male |
1 - 12 UNF |
3/4 - 16 UNF |
| YAYA-16-11C |
Type "M" Male |
Type "M" Male |
1-5/16 - 12 UNF |
1 - 12 UNF |
| YAYA-16-16C |
Type "M" Male |
Type "M" Male |
1-5/16 - 12 UNF |
1-5/16 - 12 UNF |
| YAYA-6-6C |
Type "M" Male |
Type "M" Male |
9/16 - 18 UNF |
9/16 - 18 UNF |
| YAYA-8-6C |
Type "M" Male |
Type "M" Male |
3/4 - 16 UNF |
9/16 - 18 UNF |
| YAYA-8-8C |
Type "M" Male |
Type "M" Male |
3/4 - 16 UNF |
3/4 - 16 UNF |
|
