McDaniel Controls, Inc. Safe Zone Reflective Glo-Gauge 安全区反射式液位计
McDaniel 安全区反光式玻璃液位计Safe Zone Reflective Glo-Gauge
安全区反光式玻璃液位计-反光式玻璃液位计，设计用于在白天或黑夜中从很远的地方提高能见度。”“反光”增强功能允许操作员轻松确定“安全操作区”内的表压Safe Zone Reflective Glo-Gauge- Reflective Glo-Gauge designed for greater visibility in light of day, or, from far away in darkness of night. "Retro-reflective" enhancement allows operator to easily determine gauge pressure in "safe operating zone"
特征Features:
安全区反光式玻璃液位计的设计是为了让更大的能见度近距离在白天，或从遥远的夜晚。现在，操作员可以轻松地确定和判断操作条件是否异常。安全性是一个主要考虑因素，实心正面和铰链式吹出背面，turrent风格的情况下，4毫米厚的夹层安全玻璃镜头。设计可承受300%的满量程压力而不会导致弹簧管破裂；130%的满量程压力并保持精确耐用，脉冲/振动保护，维修功能，保修，可填充外壳，更多细节Safe Zone Reflective Glo-Gauge? was designed to allow greater visibility up close in the light of day, or from far away in the darkness of night. Operators now have the ability to easily determine and judge if operating conditions have become abnormal. Safety a major consideration, Solid front and hinged blow-out back, turrent style case, 4 mm thick laminated safety glass lens. Designed to withstand 300% full-scale pressure without bourdon tube rupture; 130% full scale pressure and stay accurate Durable , Pulse/Vibration Protection , Repair Feature , Warranty , Fillable case , More Detail , Last Word
McDaniel Controls, Inc. Safe Zone Reflective Glo-Gauge 安全区反射式液位计资料下载
模型
MODEL |
刻度盘大小
DIAL SIZE |
可填充
FILLABLE |
连接
CONNECTION |
案例
CASE |
内部构件
INTERNALS |
特征
FEATURES |
| MPB/SA |
4 1/2 inch (130mm) |
Yes |
Options (1/4) |
Fiberglass reinforced thermoplastic |
316 Stainless Steel |
Reflective Glo-Gauge, SF/BOF. Elastomer |
| MPB/SC |
4 1/2 inch (130mm) |
Yes |
Options (1/2) |
Fiberglass reinforced thermoplastic |
316 Stainless Steel |
Reflective Glo-Gauge, SF/BOB. Elastomer |
Model MPB/SA
Process Gauges 4 1/2" Dial Size - Liquid Fillable - 1/4" NPT
| 标准和可选功能Standard and optional features |
| 刻度盘大小Dial size: |
4 1/2 inch (130mm) |
| 可填充：Fillable: |
Yes |
| 连接Connection: |
1/4" NPT or Metric |
| 案例Case: |
Fiberglass reinforced thermoplastic |
| 内部构件Internals: |
316 Stainless Steel |
| Wetted parts: |
316 Stainless steel (C Form 600 PSI & Below). (Spiral 800 PSI & Above). |
| 准确度Accuracy: |
0.5 % full scale to ASME B40.1 standard (Grade 2A) |
| 范围Ranges: |
Vacuum,Rec.,Compound,0-20,000 psi |
| 安装Mount: |
Standard Bottom Connection |
| 比例尺Scale: |
B=psi/Bar(dual scale), K=psi/kPa(dual scale),psi/kg/cm2(dual scale) |
| 选项Options: |
Reflective Glo-Gauge, Plastic lens, monel internals, Stainless Steel Tags, Colored Cases: Yellow, Red, Blue
Selected Special is G=Glow Dial |
| 填充选项Choice(s) of filling: |
GF=Glycerin, SF=Silicone |
Model MPB/SC
Process Gauges 4 1/2" Dial Size - Liquid Fillable - 1/2" NPT
| 标准和可选功能Standard and optional features |
| 刻度盘大小Dial size: |
4 1/2 inch (130mm) |
| 可填充：Fillable: |
Yes |
| 连接Connection: |
1/2" NPT or Metric |
| 案例Case: |
Fiberglass reinforced thermoplastic |
| 内部构件Internals: |
316 Stainless Steel |
| Wetted parts: |
316 Stainless steel (C Form 600 PSI & Below). (Spiral 800 PSI & Above). |
| 准确度Accuracy: |
0.5 % full scale to ASME B40.1 standard (Grade 2A) |
| 范围Ranges: |
Vacuum,Rec.,Compound,0-20,000 psi |
| 安装Mount: |
Standard Bottom Connection |
| 比例尺Scale: |
B=psi/Bar(dual scale), K=psi/kPa(dual scale),psi/kg/cm2(dual scale) |
| 选项Options: |
Reflective Glo-Gauge, Plastic Lens, monel internals, Stainless Steel Tags, Colored Cases: Yellow, Red, Blue
Selected Special is G=Glow Dial |
| 填充选项Choice(s) of filling: |
GF=Glycerin, SF=Silicone |
|
